Highlights:
  • Rack Height: 2U
  • Processor: 2x AMD EPYC 7002 Series
  • Drive Bays: 8x 3.5" Hot-swap drives
  • Supports 4x PCI-E 4.0 x16 Double-Wide cards
Contact sales for pricing

The TensorEX TS2-158632687-NTS is a 2U rack mountable server supporting 2x AMD EPYC 7002 Series processors, a maximum of 1 TB DDR4 memory, 2x 10GBASE-T LAN ports, and support for 4x NVIDIA GPUs.

NVIDIA Tesla GPU Options

ModelStandard MemoryMemory Bandwidth (GB/s)CUDA CoresTensor CoresSingle Precision (TFLOPS)Double Precision (TFLOPS)Power (W)Explore
A100 40 GB PCI-E 4.040 GB HBM2e1555691243219.59.7400Specs
V100S 32 GB PCI-E 3.032 GB HBM21134512064016.48.2250Specs
V100 32 GB PCI-E 3.032 GB HBM29005120640147250Specs
V100 16 GB PCI-E 3.016 GB HBM29005120640147250Specs
P100 16 GB PCI-E 3.016 GB HBM27323584-9.34.7250Specs
P100 12 GB PCI-E 3.012 GB HBM25493584-9.34.7250Specs
T4 PCI-E 3.016 GB GDDR632025603208.10.2475Specs
P4 PCI-E 3.08 GB GDDR51922560-5.50.1775Specs
NVIDIA Tesla GPU Servers

Processor & Chipset
Number of Processors Supported
2
Processor Socket
Socket SP3
Processor Type
  • EPYC
Processor Supported
  • 7002 Series
Thermal Design Power (TDP)
Up to 200W
Chipset Manufacturer
Intel
Chipset Model
SoC
Memory
Maximum Memory
1 TB
Memory Technology
DDR4 SDRAM
Memory Standard
DDR4-3200/PC4-25600
Number of Total Memory Slots
16
Controllers
Controller Type
SATA3
RAID Supported
No
Display & Graphics
Graphics Controller Manufacturer
ASPEED
Graphics Controller Model
AST2500
Network & Communication
Ethernet Technology
10GBASE-T
Number of Network (RF45) Ports
2
I/O Expansions
PCI Express
  • 4x PCI-E 4.0 x16 slots (Double-Wide card support)
  • 4x PCI-E 4.0 x8 slots (Full-Height, Full-Length)
  • 2x PCI-E 4.0 x16 slots (Low-Profile)
Drive Bays
Hot-Swap
  • 8x 3.5" Hot-Swap Drive Bays
Interfaces/Ports
Total Number of USB 3.1 Ports
5 (2x front, 2x rear, 1x Type A)
Number of SATA Interfaces
8
Number of NVMe Interfaces
8
LAN
  • 2x 10GBASE-T Ports
  • 1x RJ45 Dedicated IPMI Port
Onboard Video
  • 1x VGA
Serial Port / Header
1 (header)
DOM
2 Disk on Module port
Power Description
Number of Power Supplies
2
Redundant Power Supplies
Yes
Maximum Power Supply Wattage
2000 W
Certification
80 Plus Platinum
Physical Characteristics
Color
Black
Form Factor
Rack-mountable
Rack Height
2U
Height
3.43"
Width
17.25"
Depth
32.71"
