Highlights:
- Rack Height: 1U
- Processor Supported: 1x AMD EPYC 7001 Series
- Drive Bays: 2x 2.5" Hot-Swap
- Supports up to 4x Radeon Instinct GPUs
The TensorEX TS1-1728700-ARI, featuring four AMD Radeon Instinct GPUs, is designed for data scientists, immersion engineers, and product designers.
Features:
- Support 2x AMD EPYC 7001 Series Processor
- Support 4x AMD Radeon Instinct GPU
- 16x DDR4 Memory Slots
- 1U Rackmount
AMD Radeon Instinct GPU Options
| Model | Standard Memory | Memory Bandwidth (GB/s) | Compute Units | Stream Processors | Single Precision (TFLOPS) | Double Precision (TFLOPS) | Power (W) | Explore | |
|---|---|---|---|---|---|---|---|---|---|
 | Radeon Instinct MI50 32 GB | 32 GB HBM2 | 1000 | 60 | 3840 | 13.3 | 6.6 | 300 | Specs |
| Radeon Instinct MI50 16 GB | 16 GB HBM2 | 1000 | 60 | 3840 | 13.3 | 6.6 | 300 | Specs |
 | Radeon Instinct MI25 16 GB | 16 GB HBM2 | 484 | 64 | 4096 | 12.29 | .768 | 300 | Specs |
Processor & Chipset
Number of Processors Supported
1
Processor Socket
SP3
Processor Type
EPYC
Processor Supported
- 7001-Series
Average CPU Power (ACP)
Max up to 180 W
Memory
Maximum Memory
1 TB
Memory Technology
DDR4 SDRAM
Memory Standard
DDR4-2666/PC4-21300
Number of Total Memory Slots
16
Controllers
Controller Type
SATA3
Display & Graphics
Graphics Controller Manufacturer
Aspeed
Graphics Controller Model
AST2500
Network & Communication
Ethernet Technology
10GBASE-T
Number of Network (RJ-45) Ports
2
I/O Expansions
PCI Express
- 4x PCI-E 3.0 x16 slots (Full-Height / 10.5" length, Supports double width cards)
- 1x PCI-E 3.0 x16 (Full-Height / Half-Length)
Drive Bays
Hot-swap
2x 2.5" Hot-swap drive bays
NVMe
2x M.2 22110/2280 PCI-E
Interfaces/Ports
Total Number of USB Ports
3
Number of USB 3.0 Ports
3 (2x front, 1x rear)
Number of SATA Interfaces
2
LAN
- 2x RJ45 10GBASE-T Ethernet LAN Ports
- 1x RJ45 Dedicated IPMI Port
Onboard Video
1x VGA Connector
Power Description
Number of Power Supplies
2
Maximum Power Supply Wattage
1600 W
Certification
80 Plus Platinum
Physical Characteristics
Color
Black
Form Factor
Rack-mountable
Rack Height
1U
Height
1.71"
Width
17.24"
Depth
34.84"
