Highlights:
  • Number of Processors Supported: 2
  • Processor Socket: Socket P LGA-3647
  • Maximum Memory: 1.50 TB
  • Memory Standard: DDR4-2666/PC4-21300
Contact sales for pricing

No.1 Performance in industry-standard SPEC benchmarks

ASUS servers feature exclusive Performance Boost technology to achieve the best server performance and agility by tuning servers to match the requirements of workloads, letting you gain greater control of your server environment. This technology improves workload throughput by maximizing processor frequency and boost power, ideal for time-sensitive applications such as financial services or data center operations. In the BIOS you can choose from pre-configured server profiles optimized for specific workloads, maximizing overall performance and reducing server-configuration time.

Flexible design for office and data center environments

TS700-E9-RS8 features a flexible design that fits in both office and data-center environments. Its server rail kit enables easy integration into a data-center rack server, making TS700-E9-RS8 a perfect choice for system administrators who value easy upgradeability and deployment.

Tool-less component replacement design for hassle-free maintenance

TS700-E9-RS8 features an easy-to-service design that helps maximize system uptime by enabling system administrators to perform maintenance and upgrade system components easily with no tools required to replace the system components, including HDD module cage, 5.25-inch drive, and front and rear system fans.

Platinum PSU support

TS700-E9-RS8 supports redundant 800W 80 Plus Platinum power supply, which are 96%+ efficient, directly reducing operating costs and capital expenses. The 1+1 power-supply design allows the server to keep working even if one power supply requires maintenance, enabling uninterrupted operation.

High expandability and scalability

Seven PCIe slots and support for optional ASUS PIKE II add-on cards, including HAB/RAID and 10G LAN cards, ensures great expandability and scalability for a diverse array of storage and networking applications.

Exclusive Thermal Radar Technology for Energy Efficiency

TS700-E9-RS8 features ASUS-exclusive Thermal Radar technology with ambient sensors for internal and external temperature monitoring, and dynamic fan-curve adjustment, which lowers fan power consumption by up to 20% and reduces total cost of ownership - ideal for data centers with extreme workloads.

Multiple graphics card support

TS700-E9-RS8 accommodates two dual-slot graphics cards with a two true PCIe 3.0 x16 links to unleash maximum graphic performance. With support for NVIDIA Quadro and AMD CrossFireX configurations, TS700-E9-RS8 is an excellent choice for content creators, mechanical or architectural engineers, and anyone with processing-intensive workloads.

Supports up to 12 DDR4 ECC memory

TS700-E9-RS8 supports up to 12 DDR4 error-correcting code (ECC) memory modules to ensure fast and responsive system performance, even when simultaneously running multiple RAM-intensive applications, such as video, audio and image editing programs.

Comprehensive IT Infrastructure Management

TS700-E9-RS8 offers optional choice of iKVM module and is bundled with ASUS Control Center to provide comprehensive out-of-band and in-band management features for small and mid-size businesses.

The ASMB9-iKVM module supports remote BIOS updates, fan control, standalone KVMs, video recording, and BSOD capture, providing around-the-clock remote monitoring and diagnostics - even if the operating system is down or offline - through a user-friendly, web-based graphical interface that works with all major browsers.

General Information
Manufacturer
ASUS Computer International
Manufacturer Website Address
http://usa.asus.com
Brand Name
Asus
Product Series
TS700-E9-RS8
Product Name
TS700-E9-RS8 Barebone System
Product Type
Barebone System
Processor & Chipset
Number of Processors Supported
2
Processor Socket
Socket P LGA-3647
Processor Supported
  • Xeon Platinum
  • Xeon Gold
  • Xeon Silver
  • Xeon Bronze
  • 64-bit Processing
    Yes
    Chipset Manufacturer
    Intel
    Chipset Model
    C621
    Memory
    Maximum Memory
    1.50 TB
    Memory Technology
    DDR4 SDRAM
    Memory Standard
    DDR4-2666/PC4-21300
    Number of Total Memory Slots
    12
    Controllers
    Controller Type
    Serial ATA/600
    RAID Supported
    Yes
    Display & Graphics
    Graphics Controller Manufacturer
    ASPEED
    Graphics Controller Model
    AST2500
    Graphics Memory Capacity
    64 MB
    Network & Communication
    Ethernet Technology
    Gigabit Ethernet
    I/O Expansions
    Number of Total Expansion Bays
    11
    Number of External 5.25" Bays
    3
    Number of 3.5" Bays
    8
    Number of Total Expansion Slots
    7
    Number of PCI Express x16 Slots
    7
    Interfaces/Ports
    Total Number of USB Ports
    12
    Number of SATA Interfaces
    8
    Software
    Operating System Supported
  • Windows Server 2016
  • Windows Server 2012 R2
  • Windows 10 x64
  • SuSE Linux Enterprise Server
  • CentOS
  • Ubuntu Linux
  • Red Hat Fedora Core
  • Power Description
    Input Voltage
  • 120 V AC
  • 230 V AC
  • Number of Power Supplies Installed
    2
    Maximum Power Supply Wattage
    800 W
    Physical Characteristics
    Form Factor
    Tower
    Rack Height
    5U
    Height
    17.9"
    Width
    8.5"
    Depth
    21.5"
    Weight (Approximate)
    40.41 lb
