Highlights:
  • Application/Usage: Outdoor | Wireless Data Network
  • Directivity: Directional
  • Product Type: Antenna
  • Condition: New
Contact sales for pricing
  • Up to 300Mbps on 5GHz wireless data rates
  • 23dBi high-gain directional 2×2 MIMO antenna and a dedicated metal reflector, ideal for long-distance application
  • Excellent beam directivity, improved latency and noise cancellation
  • Innovative snap-lock parts make for fast assembly and a sturdy structural design keeps CPE610 stable even in strong winds
  • Durable IP65 weatherproof enclosure along with 15 kV ESD and 6 kV lightning protection ensures all-weather suitability
  • TP-Link Pharos MAXtream TDMA technology improves throughput, capacity and latency performance
  • Pharos Control gives administrators a free, centralized management system
  • Passive PoE supports to allow flexible deployment and convenient installation

2×2 MIMO
MAXtream TDMA
23dBi directional antenna and professional structural stability for long-distance outdoor Wi-Fi transmission.

Professional-standard 23dBi Directional
Antenna for Long-range Wireless Transmission

With 23dBi high-gain directional 2×2 MIMO Cassegrain antenna and dedicated metal reflector, the CPE610 provides excellent beam directivity, improved latency and noise immunity. Professional performance, coupled with user-friendly design, makes the 5GHz 300Mbps 23dBi Outdoor CPE610 an ideal choice and cost effective solution for outdoor wireless networking applications.

Stable Structural Design and Flexible Installation

Snap-lock parts make assembly simple and convenient
Pole mount kits and the freedom of three-axis alignment facilitate flexible installation
Sturdy design ensures stability in windy conditions

Compact and
Lightweight Packaging

Small and lightweight boxes
benefit shipping, logistics and retail.

Pharos Control - Centralized Management System

CPE610 comes equipped with Pharos Control centralized management software, helping users easily manage all devices in their network from a single PC. Functions include device iscovery, status monitoring, firmware upgrading, and network maintenance. An intuitive web-based interface- PharOS - provides an alternative management method, and allows professionals to access more detailed configurations.

General Information
Manufacturer
TP-LINK Technologies Co., Ltd
Manufacturer Part Number
CPE610
Manufacturer Website Address
http://www.tp-link.com/us
Brand Name
TP-Link
Product Model
CPE610
Product Name
5GHz 300Mbps 23dBi Outdoor CPE
Product Type
Antenna
Technical Information
Directivity
Directional
Frequency
5.15 GHz to 5.85 GHz
Antenna Gain
23 dBi
Physical Characteristics
Height
14.4"
Width
11"
Depth
8.1"
Form Factor
Pole
Miscellaneous
Application/Usage
  • Outdoor
  • Wireless Data Network
  • Package Contents
    • 5GHz 300Mbps 23dBi Outdoor CPE
    • 24V 0.5A Passive PoE Adapter
    • Pole Mounting Straps
    • AC Power Cord
    • Installation Guide
    Environmentally Friendly
    Yes
    Environmental Certification
    RoHS
