SMC-MBD-X11SDW-14C-TP13F-O-00
MPN: MBD-X11SDW-14C-TP13F-O

Supermicro MBD-X11SDW-14C-TP13F-O Motherboard - Embedded Intel Xeon D-2173IT - SOC

Highlights
General Information
Manufacturer
Supermicro Computer, Inc
Manufacturer Part Number
MBD-X11SDW-14C-TP13F-O
Manufacturer Website Address
http://www.supermicro.com
Brand Name
Supermicro
Product Model
X11SDW-14C-TP13F
Product Name
X11SDW-14C-TP13F Server Motherboard
Product Type
Server Motherboard
Processor & Chipset
Chipset Manufacturer
Intel
Total Processor Supported
1
Processor Socket
Socket BGA-2518
Integrated Processor
Integrated Processor Type
Xeon
Integrated Processor Model
D-2173IT
Integrated Processor Speed
1.70 GHz
Integrated Processor Cache
19 MB
Integrated Processor Core
Tetradeca-core (14 Core)
Memory
Number of Memory Slots
4
Memory Form Factor
  • DIMM
  • RDIMM
  • LRDIMM
    • Maximum Memory Supported
    512 GB
    Memory Technology
    DDR4 SDRAM
    Memory Speed Supported
  • 2666 MHz
  • 2400 MHz
  • 2133 MHz
    • I/O Controller
    Controller Type
    Serial ATA/600
    Video
    Onboard Video
    On-board Video Chipset
    Graphics Controller Model
    AST2500
    Network & Communication
    Gigabit Ethernet
    Yes
    10Gigabit Ethernet
    Yes
    I/O Expansions
    Total Number of Expansion Slots
    1
    Total Number of PCI Express Slots
    1
    Number of PCI Express x32 Slots
    1
    Interfaces/Ports
    Total Number of USB Ports
    2
    Number of USB 3.1 Ports
    2
    Number of Network (RJ-45) Ports
    11
    Onboard Interfaces
    Number of SATA Interfaces
    4
    Number of M.2 Interfaces
    3
    Total Number of Onboard USB Ports
    4
    Number of Onboard USB 2.0 Ports
    4
    Physical Characteristics
    Form Factor
    Proprietary Form Factor
    Width
    10"
    Depth
    8"
    Miscellaneous
    Package Contents
    • X11SDW-14C-TP13F Server Motherboard
    • 4 x I/O Cables
    • 1 x I/O Shield
    • 1 x Quick Installation Guide
    • 1 x VGA Cable
    Compatibility

    Chassis:

    • SC513BTQC-350WB
    • SC513BTQC-350WB
    Country of Origin
    Taiwan
    Environmentally Friendly
    Yes
    Environmental Compliance
    Restriction of Hazardous Substances (RoHS)
    Warranty
    Limited Warranty
    1 Year
