About
Specifications
The AMD Radeon™ R9 295X2 graphics card is the world's fastest, period. A mammoth eight gigabytes of memory and more than 11.5 teraflops of computing power help this card do what it was built to do: be the undisputed graphics champion.
About
The AMD Radeon™ R9 295X2 graphics card is the world's fastest, period. A mammoth eight gigabytes of memory and more than 11.5 teraflops of computing power help this card do what it was built to do: be the undisputed graphics champion.
Specifications
General Information
Manufacturer
Sapphire, Inc
Manufacturer Part Number
21234-00-40G
Manufacturer Website Address
http://www.sapphiretech.com
Brand Name
Sapphire
Product Name
Radeon R9 295X2 Graphic Card
Product Type
Graphic Card
Technical Information
Digital Signal
Yes
API Supported
Multi-GPU Technology
CrossFireX
Number of Monitors Supported
5
Features
Processor & Chipset
Chipset Manufacturer
AMD
Chipset Line
Radeon
Chipset Series
R9 200
Chipset Model
R9 295X2
Number of GPUs
2
GPU Clock
1.02 GHz
Number of Stream Processors
5632
Memory
Standard Memory
8 GB
Memory Speed
5000 MHz
Memory Technology
GDDR5
Bus Width
1024 bit
Interfaces/Ports
Host Interface
PCI Express 3.0 x16
DVI
Yes
Total Number of DVI Outputs
1
Dual Link DVI Supported
Yes
Mini DisplayPort
Yes
Number of Mini DisplayPort Outputs
4
Physical Characteristics
Slot Space Required
Triple
Form Factor
Plug-in Card
Cooler Type
Fan Cooler
Height
41.3"
Thickness
1.5"
Length
12.1"
Miscellaneous
System Requirements
- PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
- Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/Pages/listing.aspx
- 8192 MB Minimum of system memory.
- Installation software requires CD-ROM drive.
- DVD playback requires DVD drive.
- Blu-ray™ / HD DVD playback requires Blu-ray / HD DVD drive.
- A display with digital input (HDMI, DisplayPort or DVI) is required
- System power supply with two 8-pin PCIe® power connectors that are each capable of supplying 28 A of dedicated current
- System case with at least one location for a screw-mounted, 120 mm × 120 mm chassis fan. The case should also allow appropriate air flow and cooling of all system components
- Windows Vista
- Windows 7
- Windows 8
Platform Supported
PC
