ABOUT
The 945GC Network (MS-96C4 V1.X), an excellent server board from MSI. Based on the innovative Intel 945GC & ICH7 chipsets for optimal system efficiency, the 945GC Network accommodates the latest Intel AtomTM processor, single-core (230) & dual-core (330) (Diamondville) and supports up to two unbuffered non-ECC DDR2 400/533 DIMM slots to provide the maximum of 2GB memory capacity. In the entry-level and mid-range market segment, the 945GC Network can provide a high-performance solution for today's front-end and general purpose server, as well as in the future.
See More
SPECIFICATIONS
General Information
Manufacturer
MSI
Manufacturer Part Number
609-96C4-03S
Manufacturer Website Address
http://www.msi.com
Brand Name
MSI
Product Model
945GC Networks
Product Name
945GC Networks Server Motherboard
Product Type
Server Motherboard
Processor & Chipset
Chipset Manufacturer
Intel
Total Processor Supported
1
Processor Technology
Hyper-Threading Technology
Processor Supported
Atom
Front Side Bus
533 MHz
64-bit Processing
Yes
Memory
Number of Memory Slots
2
Maximum Memory
2 GB
Memory Standard
Memory Technology
DDR2 SDRAM
Memory Speed Supported
I/O Controller
Controller Type
Video
Onboard Video
On-board Video Chipset
Graphics Controller Manufacturer
Intel
Graphics Controller Model
945GC
Network & Communication
Gigabit Ethernet
Yes
I/O Expansions
Number of Total Expansion Slots
1
Number of Mini PCI Slots
1
Interfaces/Ports
Total Number of USB Ports
2
Number of USB 2.0 Ports
2
Serial Port
Yes
VGA
Yes
Network (RJ-45)
Yes
Onboard Interfaces
Number of IDE Interfaces
1
Number of SATA Interfaces
2
Total Number of Onboard USB Ports
1
Onboard LEDs Header
Yes
Physical Characteristics
Form Factor
Micro ATX
Width
9.6"
Depth
9.3"
Miscellaneous
Additional Information
1 Compact Flash Type socket, supports Ultra DMA 66/100/133 mode
Environmentally Friendly
Yes
Environmental Certification
WEEE
Warranty
Limited Warranty
3 Year
