MPN: 20-90051790
Kramer 20-90051790 VS-411UHD 4x1 4K60 4:2:0 HDMI Auto Switcher with Audio
Highlights
About
Specifications
The VS-411UHD is an automatic switcher for 4K@60Hz (4:2:0) HDMI and analog audio signals. The VS-411UHD automatically switches one of four HDMI inputs to a predefined or last connected input whenever the currently active video signal is interrupted or whenever a higher-priority video signal is detected. They also support Kramer's Step-in over HDMI technology.
- Max. Data Rate - 8.91Gbps (2.97Gbps per graphic channel).
- Max. Resolution - 4K@60Hz (4:2:0).
- Step-In Over HDMI Technology.
- HDTV Compatible.
- Active Switching - Selectable manual or fast auto switching according to last connected or preset priority.
- Compliance - HDMI 1.4, HDCP 1.4 and DVI 1.0.
- HDMI 1.4 Support - Deep Color, 3D, up to 7.1 uncompressed audio channels, ARC (supported on Input 1 only).
- HDMI ARC De-embedding - From output to balanced stereo audio line, uncompressed.
- Automatic Video Input Detection & Selection.
- Auto Power Off - When no HDMI input for 10 seconds (selectable).
- Selectable HDCP Switching.
- EDID Configuration Options.
- Default EDID.
- Contact Closure - For remote manual switching override.
- Audio Embedding/De-embedding.
- Stereo Analog Audio Input Per Port.
- Balanced Stereo Audio Output.
- Lock Button - To prevent tampering.
- Firmware Upgrade - Over RS-232, mini-USB.
- Software Support - Protocol 3000, EDID Designer, K-Upload via RS-232.
- Varied Control Options - Front panel buttons, contact closure, IR, RS-232 Protocol 3000.
