DP35DP Desktop Board in the ATX form factor delivers improved performance and capabilities for multimedia creation and enjoyment. With support for Intel quad-core processors and Intel Viiv processor technology , this desktop board merges the energy-efficient power of the Intel Core 2 Quad processor with enhanced expandability, and consumer electronics integration.
About
DP35DP Desktop Board in the ATX form factor delivers improved performance and capabilities for multimedia creation and enjoyment. With support for Intel quad-core processors and Intel Viiv processor technology , this desktop board merges the energy-efficient power of the Intel Core 2 Quad processor with enhanced expandability, and consumer electronics integration.
Specifications
Chipsets:
- Northbridge: Intel P35 Express
- Southbridge: Intel ICH9R
BIOS Features:
- Intel BIOS (resident in the SPI Flash device)
- Advanced Configuration and Power Interface (ACPI)
- Plug and Play
- SMBIOS
Instantly Available PC Technology:
- Support for PCI Local Bus Specification Revision 2.3
- Support for PCI Express Revision 1.0a
- Suspend to RAM support
- Wake on PCI, RS-232, front panel, PS/2 devices, USB ports, LAN, and CIR
Hardware Monitoring and Fan Control:
- Intel Quiet System Technology, delivering acoustically-optimized thermal management
- Fan speed control controllers and sensors integrated into the ICH9R
- Thermal sensors in the processor, 82P35 MCH, and 82801IR ICH9R
- Power supply monitoring of five voltages (+5 V, +12 V, +3.3 VSB, +1.25 V, and +VCCP) to detect levels above or below acceptable values
- Thermally monitored closed-loop fan control, for all three fans, that can adjust the fan speed or switch the fans on or off as needed
Power Management:
- Software support through Advanced Configuration and Power Interface (ACPI)
- Hardware support:
- Power connector
- Fan headers
- LAN wake capabilities
- Instantly Available PC technology
- Wake from USB
- Power Management Event signal (PME#) wake-up support
- Intel Quick Resume Technology Drivers (Intel QRTD) (optional)
- Wake from Consumer IR
