Highlights:
  • Product Type: SAS Controller
  • Host Interface: PCI Express 3.0 x8
  • Platform Supported: PC | Linux
  • RAID Levels: 0 | 1 | 5 | 10 | 50 | JBOD
Contact sales for pricing

Email, file, SharePoint, and similar critical apps must scale easily over time while remaining both highly protected and easily manageable. That's where the MegaRAID® SAS 9341-8i 12Gb/s SAS and SATA RAID controller card can add real value. Designed for small and medium businesses (SMBs) with tower and rack-mounted servers, it provides the headroom required for future growth at an affordable price point.

  • Connect up to 64 SATA or SAS drives in non-RAID (JBOD) mode or 32 drives in RAID mode with eight internal 12Gb/s SATA and SAS ports
  • Support high-bandwidth applications with PCIe® 3.0 connectivity
  • Fit into 1U/2U rack-mounted servers and compact servers with low-profile form factor
  • Balance protection and performance for critical applications with RAID levels 0, 1, 5, 10 and 50
General Information
Manufacturer
Broadcom Inc
Manufacturer Part Number
05-26106-00
Manufacturer Website Address
http://www.broadcom.com
Brand Name
Broadcom
Product Line
MegaRAID
Product Model
SAS 9341-8i
Product Name
MegaRAID SAS SAS 9341-8i SAS Controller
Product Type
SAS Controller
Technical Information
Host Interface
PCI Express 3.0 x8
Controller Type
12Gb/s SAS
RAID Supported
Yes
RAID Levels
  • 0
  • 1
  • 5
  • 10
  • 50
  • JBOD
  • Interfaces/Ports
    Total Number of SAS Ports
    8
    Number of SAS Ports (Internal)
    8
    SAS Connector Details
    2 SFF-8643
    Physical Characteristics
    Height
    2.5"
    Width
    6.6"
    Form Factor
    Plug-in Card
    Card Height
    Low-profile
    Weight (Approximate)
    1.32 lb
    Miscellaneous
    Package Contents
    • MegaRAID SAS SAS 9341-8i SAS Controller
    • QIG
    • LP Bracket
    Platform Supported
  • PC
  • Linux
  • Environmentally Friendly
    Yes
    Environmental Certification
    RoHS
