Optimized cooling design with front-parallel CPU and memory placement
The RS700-X7/PS4 is a space-saving 1U server featuring high memory and storage capacity, flexible RAID, 2+1 expansion slots, 80 PLUS Gold power supply, and quad LAN. It's designed for telecom server centers, IDC, and all small and medium businesses facing space constraints.
See More
SPECIFICATIONS
General Information
Manufacturer
ASUS Computer International
Manufacturer Part Number
RS700-X7/PS4
Manufacturer Website Address
http://usa.asus.com
Brand Name
Asus
Product Model
RS700-X7/PS4
Product Name
RS700-X7/PS4 Barebone System
Product Type
Barebone System
Processor & Chipset
Number of Processors Supported
2
Processor Socket
Socket R LGA-2011
Processor Supported
Xeon
QuickPath Interconnect Supported
Yes
QuickPath Interconnect
8 GT/s
Chipset Manufacturer
Intel
Chipset Model
C602-A
Memory
Maximum Memory
384 GB
Memory Technology
DDR3 SDRAM
Memory Standard
DDR3-1600/PC3-12800
Number of Total Memory Slots
12
Storage
Optical Drive Type
DVD-Writer
Controllers
Controller Type
Serial ATA/600
RAID Supported
Yes
RAID Levels
0, 1, 1+0, 5
Display & Graphics
Graphics Controller Manufacturer
ASPEED
Graphics Controller Model
AST2300
Graphics Memory Capacity
16 MB
Network & Communication
Ethernet Technology
Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays
5
Number of External 5.25" Bays
1
Number of 3.5" Bays
4
Number of Total Expansion Slots
2
Number of PCI Express x8 Slots
1
Number of PCI Express x16 Slots
1
Interfaces/Ports
Total Number of USB Ports
5
Number of USB 2.0 Ports
4
Network (RJ-45)
Yes
VGA
Yes
Number of SATA Interfaces
6
Software
Operating System Supported
Power Description
Number of Power Supplies Installed
1
Maximum Power Supply Wattage
600 W
Physical Characteristics
Form Factor
Rack-mountable
Rack Height
1U
Height
1.7"
Width
17.5"
Depth
24.2"
Weight (Approximate)
33.07 lb
Miscellaneous
Package Contents
- RS700-X7/PS4 Barebone System
- 1 x RS700-X7 User's Guide
- 1 x ASUS ASWM Enterprise User's Guide
- 1 x Bag of Screws
- 1 x AC Power Cable
- 1 x RS700-X7 Support DVD
- 1 x ASWM ENTERPRISE DVD
- 1 x ASMB6 SERIES DVD
- 1 x ASMB6 User's Guide
Compatibility
- VMWare ESX4.1
- VMWare ESXi4.1
Certifications & Standards
Safety:
- Europe (CE, EN55022 compliance to EU Directive 89/366/EEC)
EMI:
- US (FCC, CFR47 Part 15, Class A)
- Europe (CE, EN55022 & EN55024)
- Australia (C-TICK)
- Taiwan (BSMI)
Environmentally Friendly
Yes
Environmental Certification
RoHS
Warranty
Limited Warranty
3 Year
