Highlights:
  • Number of Processors Supported: 1
  • Processor Socket: Socket H4 LGA-1151
  • Maximum Memory: 64 GB
  • Memory Standard: DDR4-2133/PC4-17000
Contact sales for pricing

Zen-quiet and energy-saving

RS100-E9-PI2 delivers excellent noise mitigation, lowest as 30 dB, which is lower than the noise output of an average projector at 42dB. It also ships with high efficiency motherboard design and power module that reduces both power consumption and power loss - and that means great energy-cost savings for your organization.

Flexible deployment options in a compact rack form factor

With a short 15 chassis, RS100-E9-PI2 easily fits in diverse rack cabinet, largely increasing density per rack to save space. In addition, it offers the ideal size for IT deployment, which also saves considerable cost when setting up a data center.

General Information
Manufacturer
ASUS Computer International
Manufacturer Part Number
RS100-E9-PI2
Manufacturer Website Address
http://usa.asus.com
Brand Name
Asus
Product Model
RS100-E9-PI2
Product Name
RS100-E9-PI2 Barebone System
Product Type
Barebone System
Processor & Chipset
Number of Processors Supported
1
Processor Socket
Socket H4 LGA-1151
Processor Supported
Xeon
64-bit Processing
Yes
Chipset Manufacturer
Intel
Chipset Model
C232
Memory
Maximum Memory
64 GB
Memory Technology
DDR4 SDRAM
Memory Standard
DDR4-2133/PC4-17000
Number of Total Memory Slots
4
Controllers
Controller Type
Serial ATA
RAID Supported
Yes
Display & Graphics
Graphics Controller Manufacturer
ASPEED
Graphics Controller Model
AST2400
Graphics Memory Capacity
32 MB
Network & Communication
Ethernet Technology
Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays
3
Number of External 5.25" Bays
1
Number of 3.5" Bays
2
Number of Total Expansion Slots
1
Number of PCI Express x16 Slots
1
Interfaces/Ports
Total Number of USB Ports
6
Number of USB 3.0 Ports
4
Software
Operating System Supported
  • Windows Server 2012 R2
  • Windows Server 2012
  • Red Hat Enterprise Linux
  • SuSE Linux Enterprise Server
  • CentOS
  • Power Description
    Input Voltage
  • 120 V AC
  • 230 V AC
  • Number of Power Supplies Installed
    1
    Maximum Power Supply Wattage
    250 W
    Physical Characteristics
    Form Factor
    Rack-mountable
    Rack Height
    1U
    Height
    1.7"
    Width
    15"
    Depth
    16.9"
    Weight (Approximate)
    11.68 lb
    Miscellaneous
    Environmentally Friendly
    Yes
    Environmental Certification
    RoHS
