Highlights:
  • Backup/Run Time (Full Load): 3 Minute
  • Output Voltage: 120 V AC
  • Receptacles: 3 x NEMA 5-15R
  • Subcategory: UPS
Contact sales for pricing

Protect your electronics with this 6-outlet, 120-volt battery backup system. 300-watt back-UPS features a surge energy rating of 480 joules. Serial connection lets you use your PC to access additional power protection and management features for your uninterruptible power supply (UPS) through a serial port. Disconnected battery notification warns you when a battery is not available to provide backup power. Cold-start capability provides temporary battery power when the utility power is out. Dataline surge protection protects connected equipment from power surges on the data lines. Hot-swappable batteries ensure clean, uninterrupted power to your protected equipment while the batteries are being replaced. Wiring fault indicator informs you of potentially dangerous wiring problems in the wall circuit.

General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
BK500
Manufacturer Website Address
http://www.schneider-electric.com
Brand Name
APC by Schneider Electric
Product Line
Back-UPS
Product Series
CS
Product Name
BK500 120V Backup System
Product Type
Line-interactive UPS
Technical Information
Plug/Connector Type
NEMA 5-15P
Receptacles
3 x NEMA 5-15R
Dataline Protection
RJ-11
Cord Length
6 ft
Power Description
Load Capacity
500 VA
Input Voltage
110 V AC
Output Voltage
120 V AC
Power Consumption
300 W
Waveform Type
Step Wave
Surge Energy Rating
480 J
Management
Alarm
  • On Battery
  • Low Battery
  • Overload
  • Controls/Indicators
    Status Indicators
    LED status display with On Line, On Battery, Replace Battery, Site wiring fault and Overload Indicators
    Interfaces/Ports
    Serial Port
    Yes
    USB
    Yes
    Battery Information
    Battery Characteristics
    Spill-proof, Maintenance-free
    Battery Chemistry
    Sealed Lead Acid (SLA)
    Backup/Run Time (Full Load)
    3 Minute
    Backup/Run Time (Half Load)
    15 Minute
    Typical Battery Recharge Time
    8 Hour
    Environmental Conditions
    Maximum Operating Temperature
    113°F (45°C)
    Sound Emission
    45 dB(A)
    Thermal Dissipation
    7.03 W
    Physical Characteristics
    Color
    Beige
    Height
    6.5"
    Width
    3.6"
    Depth
    11.2"
    Weight (Approximate)
    13.80 lb
    Miscellaneous
    Package Contents
    • User Manual
    • Velcro Cord Management Straps Kit
    • CD with software
    • USB cable
    Additional Information
    • Additional Surge Protected Outlets
    • Cord Management
    • Software
    • USB compatible
    Certifications & Standards
    • FCC Part 15 Class B
    • Industry Canada
    • UL 1778
    • cUL Listed
    Recycled
    No
    Assembly Required
    No
    Energy Star
    Yes
    Environmentally Friendly
    Yes
    Environmental Certification
    ENERGY STAR
    Country of Origin
    Philippines
    Warranty
    Limited Warranty
    3 Year
    Additional Warranty Information

    3 years warranty
