About
Specifications
Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (12)C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.
About
Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (12)C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.
Specifications
General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
AP9565
Manufacturer Website Address
http://www.schneider-electric.com
Brand Name
APC by Schneider Electric
Product Line
NetShelter
Product Series
Basic
Product Name
Basic Rack 3.68kVA PDU
Packaged Quantity
1 Each
Product Type
PDU
Technical Information
PDU Type
Basic
Plug/Connector Type
IEC 60320 C20
Receptacle Type
IEC 60320 C13
Receptacle Detail
12 x IEC 60320 C13
Power Description
Input Voltage
Input Voltage Range
120 V AC - 240 V AC
Output Voltage
Power Rating (VA)
3680 VA
Physical Characteristics
Color Family
Black
Product Color
Black
Mounting Orientation
Horizontal
Mounting Preference
No Preference
Mount Type
Rack-mountable
Placement
Rack Height
1U
Cord Length
8.20 ft
Height
1.7"
Width
17.6"
Depth
2.2"
Weight (Approximate)
4.52 lb
Miscellaneous
For Country/Region
United States
Package Contents
Certifications & Standards
cUL Listed|CE|Queensland Australia|UL Listed|VDE
Optimized Energy Efficiency
Yes
Product Take Back Program
Yes
REACH free of SVHC
Yes
Lead Free
Yes
REACH Declaration URL
https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759568&lang=en-us
EU RoHS Declaration URL
https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759568&lang=en-us
Environmental Profile Availability
https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1512009_EN
End of Life Manual Availability
https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512009_EN
California Proposition 65 Warning
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
WEEE Statement
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty
2 Year
Parts Warranty/Labor
2 Year
Additional Warranty Information
2 years repair or replace
