About
Specifications
It is a metered rack PDU designed for 1U horizontal mounting. It supports a maximum current of 16A and operates at 208-230V. The PDU features 8 IEC 60320 C13 outlets and an 8.2-foot power cord with an IEC 60320 C20 plug. It has a load capacity of 3300 VA and includes a cord retention bracket, installation guide, and rack mounting brackets.
About
It is a metered rack PDU designed for 1U horizontal mounting. It supports a maximum current of 16A and operates at 208-230V. The PDU features 8 IEC 60320 C13 outlets and an 8.2-foot power cord with an IEC 60320 C20 plug. It has a load capacity of 3300 VA and includes a cord retention bracket, installation guide, and rack mounting brackets.
Specifications
General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
AP7821B
Manufacturer Website Address
http://www.schneider-electric.com
Brand Name
APC by Schneider Electric
Product Name
Rack PDU, Metered, 1U, 16A, 208/230V, (8) C13
Product Type
PDU
Technical Information
PDU Type
Metered
Plug/Connector Type
IEC 60320 C20
Power Description
Input Voltage
Output Voltage
Input Current
20 A
Management
Management
- SNMP
- Telnet
- HTTP
- SSH
Interfaces/Ports
Network (RJ-45)
Yes
Physical Characteristics
Mounting Orientation
Horizontal
Mounting Preference
No Preference
Mount Type
Rack-mountable
Placement
Rack Height
1U
Cord Length
8.20 ft
Height
1.7"
Width
17.5"
Depth
4"
Weight (Approximate)
3.84 lb
Miscellaneous
For Country/Region
United States
Package Contents
Certifications & Standards
cUL Listed|C-tick|CE|CSA|GOST|UL Listed|VCCI|VDE
Optimized Energy Efficiency
Yes
Product Take Back Program
Yes
REACH free of SVHC
Yes
Mercury Free
Yes
Lead Free
Yes
RoHS Exemption Information
https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP7821B_ROHS_DECLARATION&p_FileName=AP7821BKIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL
https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=458562848&lang=en-us
EU RoHS Declaration URL
https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=458562848&lang=en-us
Environmental Profile Availability
https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1712014_EN
End of Life Manual Availability
https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1712014_EN
California Proposition 65 Warning
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Country of Origin
Philippines
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty
2 Year
Additional Warranty Information
2 years repair or replace
