AMX-FGN2121-SA-00
MPN: FGN2121-SA

AMX FGN2121-SA JPEG 2000 Digital Cinema Grade Video over IP Encoder

Highlights
NMX-ENC-N2121 encode and distribute sources of almost any format onto an existing IP network making that stream available to any endpoint in the facility. Pair with the NMX-ENC-N2221 Decoder to decode streams back to DVI or HDMI format for display on any monitor. With the ability to direct any source stream to any display, large, low-cost switching and distribution systems are simple to deploy without proprietary cabling or dedicated switching hardware.

Includes IR, serial, balanced audio, two network ports (one POE), and local video pass-through port. Auto-senses analog or digital video in.

The AMX SVSI N2000 Series utilizes JPEG2000 compression for HD, cinema-grade video distribution on the LAN for applications when video quality is top priority. Users can control video quality and bandwidth usage with a simple slider control provided in the web-based user interface allowing each installation to be customized for maximum performance.

COMMON APPLICATION The NMX-ENC-N2121 is the perfect solution for matrix switching and distribution of HD, cinema-grade quality video over LAN. Common applications include enterprise, house of worship, entertainment, and stadiums.

FEATURES

  • Input and Output Scaling - Video scaling at either input or output allows seamless switching from any source, at any resolution, to any display or projector, while preserving video fidelity.
  • Power Over Ethernet (POE) - Eliminates requirement for local power supply and speeds installation. Units can still be powered locally from 12VDC allowing for easy rack-mountable, high-density installations.
  • Infrared (IR) - Infrared emitter connection allows control of low-cost, IR-only display devices.
  • Onboard Control - All N-Series encoders and decoders have on-board, built-in control capability via events that can trigger any number of TCP/UDP commands to other IP controllable devices.
  • Unlimited Scalability
  • Pass-Through DVI - DVI interface allows easy installation with local display such as desktop PC applications.
  • Stand Alone or Card - Available as a stand alone device, or card for use with NMX-ACC-N9206.
