ABOUT
Embrace the total multimedia experience right on your PC with the unbeatable value and performance of the All-In-Wonder 9600.
The All-In-Wonder 9600 gives you the power to sit back, playback, and capture or edit the finest quality TV, output to an HDTV, stream video via EAZYSHARE, and play DVDs that today's technology has to offer for the PC. Combine this with the awesome graphic rendering power of its Radeon 9600 visual processing unit, remote control freedom, plus dual VGA monitor support and you have a multimedia dynamo. With support for the latest DirectX 9.0 graphics standard, AGP 8X and up to 128MB of DDR memory, the All-In-Wonder 9600 launches gamers into immersive 3D game play at blistering speeds right out of the box.
See More
SPECIFICATIONS
General Information
Manufacturer
Advanced Micro Devices, Inc
Manufacturer Part Number
100-714116
Manufacturer Website Address
http://www.amd.com
Brand Name
AMD
Product Line
All-In-Wonder
Product Name
All-In-Wonder 9600 Graphics/TV Tuner Card
Package Type
Retail
Product Type
Graphic Card
Technical Information
Maximum Resolution
2048 x 1536
Analog Signal
Yes
API Supported
Video System
NTSC
TV Tuner
Yes
Processor & Chipset
Chipset Manufacturer
ATI
Chipset Line
Radeon
Chipset Series
9
Chipset Model
9600
GPU Clock
325 MHz
Memory
Standard Memory
128 MB
Memory Technology
DDR SDRAM
Bus Width
128 bit
Interfaces/Ports
Host Interface
AGP 8x
VGA
Yes
Number of VGA Outputs
2
Audio Line In
Yes
Audio Line Out
Yes
S-Video
Yes
Number of S-Video Inputs
1
Number of S-Video Outputs
1
Composite Video
Yes
Number of Composite Video Inputs
1
Number of Composite Video Outputs
1
Miscellaneous
Package Contents
Documentation:
- All-In-Wonder Radeon 9600 Installation and Setup Guide English
- All-In-Wonder Radeon 9600 Install Poster E/F/G/S
- ATI Remote Wonder Installation Instruction
Software:
- All-In-Wonder 9600 Installation CD
Hardware & Cables:
- All-In-Wonder 9600 Graphics/TV Tuner Card
- Video / Audio Input Dongle
- RF Remote Control USB Receiver Unit (Remote Wonder)
- USB Receiver Unit (Remote Wonder)
- Battery "AAA" 4 Pack
Additional Information
It's Your Total Entertainment Hub:
- Expand your personal entertainment world when you bring together TV, DVD and video playback with on-demand features, wireless remote control and a 125 channel stereo TV receiver:
- An all-in-one TV tuner with TV-ON-DEMAND (records TV programs, pauses live TV, has optional picture-in-picture (PiP) capability and lets you schedule broadcasts directly to your PC)
- Gemstar GUIDE Plus+ software organizes TV listings and makes searching for and scheduling programs a snap
- Drive 2 VGA monitors or a VGA monitor and TV output simultaneously. Control independent resolution and refresh rates for any two connected displays
- Drive an HDTV-ready Television using the optional VGA->YPrPb adapter available from ati.com. Enable a non-interlaced high resolution display in the family room
- Enjoy the convenience of over 30 foot wireless radio frequency range (including through walls) with the user friendly control pad utilizing the REMOTE WONDER remote control device. The REMOTE WONDER lets you operate your PC mouse without being tied to your system with a cable
- Includes a simple, forward facing input block with s-video, composite video inputs and stereo audio input
- THRUVIEW creates live, translucent TV, video and DVD windows for easy desktop access
- New EAZYLOOK provides easy to read on-screen information for TV and DVDs. Drive MULTIMEDIA CENTER from the couch using the REMOTE WONDER
- With the EASYSHARE feature you can share the power of the All-In-Wonder 9600 with all of your home networked computers
- TV Antenna Input
System Requirements
- Intel Pentium 4/III/II/Celeron, AMD K6/Athlon or compatible with AGP 8X (0.8V)/4X (1.5V) slot
- 128 MB of system memory
- CD-ROM drive for software installation
- DVD drive for DVD playback
- Remote control receiver requires available USB port
- 1GHz minimum processor speed for MPEG-2 video capture
- Sound Subsystem with DirectSound drivers
- Interactive Program guide requires Internet connection for listing updates
TV-tuner requirements:
- TV signal from amplified antenna or cable
- Versions available for: NTSC (North America, Japan, and Latin America)
- Operating system support:
- Microsoft Windows 98*
- Microsoft Windows 98 Second Edition*
- Microsoft Windows Me
- Microsoft Windows 2000
- Microsoft Windows XP
- *Windows Me driver can be installed on Windows 98/98 Second Edition
Display support:
- Two VGA displays simultaneously or One VGA display connected with a TV or VCR. Independent resolution and refresh rate for any two connected displays
Platform Supported
PC
Warranty
Limited Warranty
3 Year
