The Supermicro WIO serverboard product family offers a range of new generation X11 motherboards which are designed to deliver a wide range of I/O options for accelerated computing. Users can optimize the storage and networking alternatives to accelerate performance, increase efficiency and find the perfect fit for their applications. In addition to enabling customizable configurations and optimization for multiple application requirements, Supermicro WIO SuperServers also provide attractive cost advantages and investment protection.
The Supermicro WIO SuperServer® product family supports up to: 1.5TB ECC 3DS LRDIMM or RDIMM DDR4-2666MHz memory in 12 DIMM slots, 3/6 Add-on Cards in 1U/2U, 10 SATA 3.0 (6Gbps) ports with Intel® C620 controller, hot-swap 2.5 or 3.5 drive bays, SATA3 and NVMe hybrid ports, optional NVMe drives, LAN options up to 2x 10GBase-T or 2 GbE ports, redundant Platinum Level (95%) power supplies, integrated IPMI 2.0 with KVM over dedicated LAN, and dual or single Intel® Xeon® Scalable Processor Family up to 28 cores and 205W TDP.
Supermicro WIO serverboards are optimized for general purpose, ERP/MRP, and network and security appliance applications and are compatible with the following Supermicro chassis: SC113TQ, SC116TQ, SC213A, SC825TQ, and SC815TQ.
