ABOUT
Designed for optimal performance, Supermicro's Twelve/Eight-Core AMD Opteron 6100 series processor based system is paired with AMD chipset in a high-density 1U form-factor. With best-in-class memory architecture supporting latest DDR3 memory, hot-swap SATA drive bays, latest IPMI intelligent management, and PCI-E 2.0 for improved I/O performance. These systems are ideal for HPC and minimal-downtime cluster server systems.
See More
SPECIFICATIONS
General Information
Manufacturer
Supermicro Computer, Inc
Manufacturer Part Number
AS-1042G-TF
Manufacturer Website Address
http://www.supermicro.com
Brand Name
Supermicro
Product Line
A+ Server
Product Model
1042G-TF
Product Name
A+ Server 1042G-TF Barebone System
Product Type
Barebone System
Processor & Chipset
Number of Processors Supported
4
Processor Socket
Socket G34 LGA-1944
Processor Supported
Opteron
Chipset Manufacturer
AMD
Chipset Model
SR5690
Memory
Maximum Memory
512 GB
Memory Technology
DDR3 SDRAM
Memory Standard
DDR3-1333/PC3-10600
Number of Total Memory Slots
32
Controllers
Controller Type
Serial ATA/300
RAID Supported
Yes
RAID Levels
0, 1, 1+0
Display & Graphics
Graphics Controller Manufacturer
Matrox
Graphics Controller Model
G200
Graphics Memory Capacity
16 MB
Graphics Memory Technology
DDR2 SDRAM
Network & Communication
Ethernet Technology
Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays
4
Number of External 5.25" Bays
1
Number of 3.5" Bays
3
Number of Total Expansion Slots
1
Number of PCI Express x16 Slots
1
Interfaces/Ports
Total Number of USB Ports
2
Number of USB 2.0 Ports
2
Network (RJ-45)
Yes
VGA
Yes
Power Description
Input Voltage
Number of Power Supplies Installed
1
Maximum Power Supply Wattage
1400 W
Physical Characteristics
Color
Black
Form Factor
Rack-mountable
Rack Height
1U
Height
1.7"
Width
17.2"
Depth
27.8"
Miscellaneous
Package Contents
- A+ Server 1042G-TF Barebone System
- 1 x Super H8QGi+-F Motherboard
- 1 x 1U SC818TQ-1400UB Chassis (Black)
- 1 x 8-pin to 8-pin Ribbon Cable for SGPIO (Supports Up to 4 Drives)
- 1 x 48cm SATA round S-S
- 1 x 70cm, internal USB cable for slim USB DVD ROM
- 1 x Mini-SATA to USB adapter for slim DVD
- 1 x Slim SATA DVD kit
- 1 x Support 3x SAS/SATA HDD; SATA con
- 6 x 40x56mm 4-pin PWM Cooling Fans
- 1 x Fan Holder For Six 56mm Counter-rotating Fans
- 3 x SCA Type Assy Without Logo, Black
- 4 x 1U Passive CPU HS for AMD Socket G34
- 1 x 1U open rack bracket set for CSE-PT51L, MCP-290-00054-0N
- 1 x Rail set for SC808, 809, 818
- 1 x 1400W 1U Gold Level Power Supply with PMBus and WX106MM
- 1 x Power Distributor Board
- 1 x Power Distributor Cover For SC818 Chassis
- 1 x EMI filter for AC power cable
- 1 x Riser card 1U PCI-E 16x to 16x
- 1 x Mylar Air Shroud (for H8QG6/i+)
Environmentally Friendly
Yes
Environmental Certification
80 Plus Gold
Warranty
Limited Warranty
3 Year
