SPP-R-FSP600-80ETN-00
MPN: R-FSP600-80ETN

Sparkle Power R-FSP600-80ETN 600 Watts ATX12V V2.3 EPS12V V2.92 Switching Power Supply

Highlights
General Information
Manufacturer
Sparkle Power, Inc
Manufacturer Part Number
RFSP60080ETN
Manufacturer Website Address
http://www.sparklepower.com
Brand Name
Sparkle Power
Product Line
Magna Platinum
Product Name
600 Watts ATX12V V2.3 EPS12V V2.92 Switching Power Supply (Meet 2013 ErP)
Product Type
Power Supply
Technical Information
Specification Compliance
ATX12V/EPS12V
Power Factor Correction (PFC)
Active
Number of Fans
1
Protection Type
  • Output Over Voltage
  • Short Circuit
  • Over Current
    • Reliability
    MTBF
    100000 Hour
    Power Description
    Number of +12V Rails
    4
    Input Voltage Type
    AC
    Input Voltage
  • 110 V AC
  • 220 V AC
    • Input Voltage Range
    90 V AC - 264 V AC
    Output Voltage
  • 3.3 V
  • 5 V
  • 12 V
  • -12 V
    • Output Voltage Detail
  • 3.3 V @ 20 A
  • 5 V @ 18 A
  • 12 V @ 18 A
  • -12 V @ 300 mA
  • 5 V @ 3 A
    • Input Current
  • 8 A @ 110V
  • 4 A @ 220V
    • Output Current
  • 20 A
  • 18 A
  • 300 mA
  • 3 A
    • Output Power
    600 W
    Interfaces/Ports
    Receptacles
  • 24-pin ATX12V Motherboard
  • 8-pin EPS12V Motherboard
  • 6 x Serial ATA
  • PCI-E
    • Physical Characteristics
    Form Factor
    Internal
    Height
    3.4"
    Width
    5.9"
    Depth
    5.5"
    Miscellaneous
    Environmentally Friendly
    Yes
    Energy Efficiency Certification
    80 Plus Platinum
    Energy Efficiency Compliance
    Energy-related Products Directive (ErP)
    Environmental Compliance
    Restriction of Hazardous Substances (RoHS)
    Warranty
    Limited Warranty
    5 Year
