Highlights:
  • Cores: 1792 CUDA
  • 8GB Memory | 243 GB/s Bandwidth
  • 5.3 TFLOPS Single-Precision
  • Cooler Type: Fan Cooler
Contact sales for pricing

NVIDIA QUADRO P4000—THE WORLD’S MOST POWERFUL SINGLE SLOT PROFESSIONAL GRAPHICS CARD

The new NVIDIA VR Ready Quadro P4000 combines a 1792 CUDA Core Pascal GPU, large 8GB GDDR5 memory and advanced display technologies to deliver the performance and features that are required by demanding professional applications. The ability to create an expansive visual workspace of up to four 5K displays (5120 x 2880 at 60Hz) with HDR color support lets you view your creations in stunning detail. The P4000 is specially designed with the performance that is necessary to drive immersive VR environments. Additionally, you can create massive digital signage solutions by connecting multiple P4000s via Quadro Sync II.

The new Quadro P4000 combines the latest GPU architecture and display technologies to deliver the best performance and features available in a single slot professional graphics card solution. The P4000 enables users to create large, complex designs, render detailed photo realistic imagery, and create detailed, lifelike VR experiences.


Pascal GPU Architecture

Based on state-of-the-art 16nm FinFET Plus process technology to pack over 7 billion transistors and 1792 CUDA cores and up to 5.3 TFLOPs of single precision compute power. The Quadro P4000 graphics board is the industry’s most dominant single-slot form factor graphics board, which is for computationally demanding design visualization or immersive design reviews. Get real interactive experience with today’s demanding professional workflows.


NVIDIA CUDA Parallel Computing Platform

Natively execute standard programming languages like C/C++ and Fortran, and APIs such as OpenCL, OpenACC and Direct Compute to accelerates techniques such as ray tracing, video and image processing, and computation fluid dynamics.


NVIDIA Quadro Sync II

Synchronize the display and image output of up to 32 displays from 8 GPUs (connected through two Sync II boards) in a single workstation, reducing the number of machines needed to create an advanced video visualization environment. Each frame lock cable is designed with a self-locking retention mechanism to secure its connection with the frame lock connector to provide robust connectivity and maximum productivity. P4000 + Quadro Sync II turnkey bundles are available.


Available Accessories

NVIDIA SLI Bridge Kit (HBSLIBRIDGE-2W2S-KIT / HBSLIBRIDGE-2W3S-KIT) leverages multiple GPUs to dynamically scale graphics performance, enhance image quality, expand display real estate. Order PNY Part Number HBSLIBRIDGE-2W2S-KIT or HBSLIBRIDGE-2W3S-KIT depending on motherboard PCIe slot spacing.

DisplayPort to HDMI Four Pack (DP-HDMI-FOUR-PCK) Connect the Quadro P4000 to HDMI displays at resolutions up to 4K with PNY Part Number DP-HDMI-THREE-PCK. The four included DisplayPort to HDMI adapters are recommended by NVIDIA, provide outstanding image quality, and are built to professional standards.

DisplayPort to HDMI Single Pack (DP-HDMI-SINGLE-PCK) Connect the Quadro P4000 to an HDMI display at resolutions up to 4K with PNY Part Number DP-HDMI-SINGLE-PCK. The included DisplayPort to HDMI adapter is recommended by NVIDIA, provides outstanding image quality, and is built to professional standards.

DisplayPort To DVI Four Adapter (DP-DVI-QUADKIT-PB) Connect the Quadro P4000 to DVI-D SL displays at resolutions up to 1920 x 1200 with PNY Part Number DP-DVI-QUADKIT-PB. The four included DisplayPort to DVI-D SL adapters are recommended by NVIDIA, provide outstanding image quality, and are built to professional standards.

DisplayPort To VGA Cable Adapter (DP-VGA-QUADKIT-PB) Connect the Quadro P4000 to DVI-D SL displays at resolutions up to 2048 x 1536 with PNY Part Number DP-VGA-QUADKIT-PB. The four included DisplayPort to VGA adapters are recommended by NVIDIA, provide outstanding image quality, and are built to professional standards.

NVIDIA Quadro SYNC II (VCQPSYNC2-KIT) enable the creation of dazzling ultra-high resolution, perfectly synchronized displays to meet the visualization and presentation needs across industries. Designed for flexibility and scalability, Quadro Sync boards connect to select NVIDIA Quadro GPUs, synchronizing them with the displays or projectors attached to them. Quadro Sync also enables NVIDIA Quadro Mosaic™ technology on those synchronized displays and projectors, providing an easy way to scale the resolution of any application.


NVIDIA Quadro Graphics. Breakthrough in Every Form.

NVIDIA Quadro Visualization. Advanced Multi-Display and Accelerated Rendering.

General Information
Manufacturer
PNY Technologies
Manufacturer Part Number
VCQP4000-PB
Manufacturer Website Address
http://www.pny.com
Brand Name
PNY
Product Name
NVIDIA Quadro P4000 Graphic Card
Packaged Quantity
1
Package Type
Retail
Product Type
Graphic Card
Technical Information
API Supported
  • Vulkan 1.0
  • OpenCL
  • DirectX 12
  • DirectCompute
  • OpenGL 4.5
Multi-GPU Technology
SLI
Number of Monitors Supported
4
Processor & Chipset
Chipset Manufacturer
NVIDIA
Chipset Line
Quadro
GPU Architecture
Pascal
Chipset Series
P
Chipset Model
P4000
Single-Precision Performance
5.3 TFLOPS
Processor Core
1792 CUDA
Memory
Standard Memory
8 GB
Memory Technology
GDDR5
Memory Bandwidth
243 GB/s
Bus Width
256 bit
Power Description
Thermal Design Power
105 W
Interfaces/Ports
Host Interface
PCI Express 3.0 x16
DisplayPort
Yes
Number of DisplayPort Outputs
4
Physical Characteristics
Slot Space Required
Single
Form Factor
Plug-in Card
Cooler Type
Fan Cooler
Height
4.4"
Length
9.5"
Miscellaneous
Package Contents
  • NVIDIA Quadro P4000 Graphic Card
  • Stereo Connector Bracket
  • DisplayPort to DVI-D SL Adapter
  • Auxiliary Power Cable
  • Software Installation Disc for Windows 10, 8.1, 8, and 7 (64- and 32-bit)
  • Printed Quick Start Guide
Platform Supported
  • Linux
  • Mac
  • PC
Energy Star
Yes
Warranty
Limited Warranty
3 Year
