MLX-MC2309124-005-00
MPN: MC2309124-005

Mellanox MC2309124-005 Passive Copper Hybrid Cable Ethernet 10GbE QSFP to SFP+ 5m

Highlights

NVIDIA MC2309124-005 Direct Attach Copper Splitter Cable Ethernet 10GbE QSFP to SFP+ 5m

10GbE QSFP+ to SFP+ DAC Splitter Cable

NVIDIA's QSFP to SFP+ passive DAC splitter breakout cables are compliant with SFF-8431 and SFF-8436 specifications and provide connectivity between devices using QSFP port on one end to an SFP+ port on the other end. The cables use state-of-the-art signal processing technology to fill the expanding need for cost-effective data center interconnects.

NVIDIA's unique, quality, passive copper cable solutions provide a power-efficient replacement for active power connectivity, such as fiber optic cables. Optimizing systems to operate with QSFP to SFP+ passive copper splitter cables significantly reduces power consumption and enlarges the connectivity opportunities of the system.

Rigorous cable production testing ensures the best out-of-the-box installation experience, performance and durability.

Highlights

  • Compliant to industry standards:
    • InfiniBand Architecture specification
      • QSFP MSA SFF-8436
      • SFP+ MSA SFF-8431
  • BER better than 1E-15
  • Low crosstalk
  • Low insertion loss
  • Matched impedance
  • Secure latching mechanism
  • RoHS-5 compliant
