MPN: TS4-190785987

Exxact TensorEX 4U NVIDIA MGX™ Server - 2x AMD EPYC 9005 Series - TS4-190785987

Highlights

About

Specifications

The TensorEX TS4-190785987 is a 4U NVIDIA MGX™ server supporting 2x AMD EPYC 9005 Series processors and 24x DDR5 memory slots.

Specifications

Processor & Chipset

Number of Processors Supported

Processor Socket

Socket SP5 LGA-6096

Processor Type

EPYC

Processor Supported

9005-Series

Thermal Design Power (TDP)

500 W

Chipset Manufacturer

N/A

Chipset Model

SoC

Memory

Memory Technology

DDR5 SDRAM

Memory Standard

DDR5-6400/PC5-51200 RDIMM (1DPC)

Number of Total Memory Slots

Controllers

NVMe

Via SoC

Display & Graphics

Graphics Controller Manufacturer

ASPEED

Graphics Controller Model

AST2600

Network & Communication

Ethernet Technology

10GBASE-T

I/O Expansions

PCI Express

8x PCI-E 5.0 x16 FHFL slots (Supports Double-Wide cards)
4x PCI-E 5.0 x16 FHFL slots
1x PCI-E 5.0 x16 FHFL slot
2x PCI-E 3.0 x2 M.2 slot (22110/2280)

Drive Bays

Hot-swap

8x 2.5" U.2 NVMe hot-swap drive bays
Supports PCI-E 5.0 x4

Interfaces/Ports

USB Ports

1x USB 3.0 port (Rear, Type A)

Number of NVMe Interfaces

8x U.2
2x M.2

LAN

2x 10GBASE-T (10GbE) Ports
1x RJ45 Management Port

Onboard Video

1x Mini DisplayPort

Trusted Platform Module

1x TPM 2.0 (Onboard)

Power Description

Number of Power Supplies

Redundant Power Supplies

Yes (3+1)

Maximum Power Supply Wattage

3200 W

Certification

80 Plus Titanium

Physical Characteristics

Color

Black

Form Factor

Rack-mountable

Rack Height

Height

6.88"

Width

17.2"

Depth

31.4"
