MPN: TS2-170339111
Exxact TensorEX 2U NVIDIA MGX™ Server - 1x Intel Xeon 6500P/6700P Series - TS2-170339111
Highlights
Rack Height:
2U
Processor:
1x Intel Xeon 6500P/6700P Series
Drive Bays:
4x 2.5" NVMe U.2 Hot-Swap
Supports:
4x PCI-E 5.0 x16 Double-wide cards
Starting Price: $20,185.00
About
Specifications
The TensorEX TS2-170339111 is a 2U NVIDIA MGX™ Server supporting 1x Intel Xeon 6500P/6700P Series processors with 136 PCIe lanes and 16x DDR5 memory slots.
Configure this Platform or Contact Sales for Compatibility
NVIDIA Data Center
AMD Instinct
Model | Host Interface | Standard Memory | Memory Bandwidth | CUDA Cores | Tensor Cores | Single Precision (TFLOPS) | Double Precision (TFLOPS) | AI Performance | Power |
|---|---|---|---|---|---|---|---|---|---|
| RTX PRO 6000 Blackwell Server | PCIe 5.0 x16 | 96 GB GDDR7 ECC | 1.6 TB/s | 24064 | 752 | 120 | 1.97 | 4000 TOPS (FP4) | Up to 600 W |
| H200 NVL | PCIe 5.0 x16 | 141 GB HBM3e | 4.8 TB/s | 16896 | 528 | 60 | 30.2 | 3,341 TFLOPS (FP8) | Up to 600 W |
| H100 | PCIe 5.0 x16 | 80 GB HBM2e | 2 TB/s | 14592 | 456 | 51 | 25.6 | 3,341 TFLOPS (FP8) | Up to 400 W |
| L40S | PCIe 4.0 x16 | 48 GB GDDR6 | 864 GB/s | 18176 | 568 | 92 | 1.41 | 1,466 TFLOPS (FP8) | 300W |
| L40 | PCIe 4.0 x16 | 48 GB GDDR6 | 864 GB/s | 18176 | 568 | 91 | 1.41 | 724 TFLOPS (FP8) | 300W |
| L4 | PCIe 4.0 x16 | 24 GB GDDR6 | 300 GB/s | 7424 | 240 | 30 | 0.47 | 485 TFLOPS (FP8) | 72W |
About
The TensorEX TS2-170339111 is a 2U NVIDIA MGX™ Server supporting 1x Intel Xeon 6500P/6700P Series processors with 136 PCIe lanes and 16x DDR5 memory slots.
Configure this Platform or Contact Sales for Compatibility
NVIDIA Data Center
AMD Instinct
Model | Host Interface | Standard Memory | Memory Bandwidth | CUDA Cores | Tensor Cores | Single Precision (TFLOPS) | Double Precision (TFLOPS) | AI Performance | Power |
|---|---|---|---|---|---|---|---|---|---|
| RTX PRO 6000 Blackwell Server | PCIe 5.0 x16 | 96 GB GDDR7 ECC | 1.6 TB/s | 24064 | 752 | 120 | 1.97 | 4000 TOPS (FP4) | Up to 600 W |
| H200 NVL | PCIe 5.0 x16 | 141 GB HBM3e | 4.8 TB/s | 16896 | 528 | 60 | 30.2 | 3,341 TFLOPS (FP8) | Up to 600 W |
| H100 | PCIe 5.0 x16 | 80 GB HBM2e | 2 TB/s | 14592 | 456 | 51 | 25.6 | 3,341 TFLOPS (FP8) | Up to 400 W |
| L40S | PCIe 4.0 x16 | 48 GB GDDR6 | 864 GB/s | 18176 | 568 | 92 | 1.41 | 1,466 TFLOPS (FP8) | 300W |
| L40 | PCIe 4.0 x16 | 48 GB GDDR6 | 864 GB/s | 18176 | 568 | 91 | 1.41 | 724 TFLOPS (FP8) | 300W |
| L4 | PCIe 4.0 x16 | 24 GB GDDR6 | 300 GB/s | 7424 | 240 | 30 | 0.47 | 485 TFLOPS (FP8) | 72W |
