EMX-ENP550AWT_B-00
MPN: ENP550AWT_B

Enermax ENP550AWT_B NAXN 82+ ATX12V & EPS12V 550W Power Supply

Highlights
General Information
Manufacturer
Enermax Technology Corporation
Manufacturer Part Number
ENP550AWTB
Manufacturer Website Address
http://www.enermax.com
Brand Name
Enermax
Product Line
NAXN
Product Series
82+
Product Model
ENP550AWT B
Product Name
NAXN 82+ ENP550AWT B ATX12V & EPS12V Power Supply
Product Type
Power Supply
Technical Information
Specification Compliance
ATX12V/EPS12V
Efficiency
88%
Power Factor Correction (PFC)
Active
Number of Fans
1
Protection Type
  • Over Voltage
  • Under Voltage
  • Short Circuit
  • Over Power
  • Over Current
  • Over Temperature
  • Surge
  • Inrush Current
    • Reliability
    MTBF
    100000 Hour
    Power Description
    Number of +12V Rails
    2
    Input Voltage Type
    AC
    Input Voltage
  • 110 V AC
  • 220 V AC
    • Input Voltage Range
    100 V AC - 240 V AC
    Output Voltage
  • 3.3 V DC
  • 5 V DC
  • 12 V DC
  • -12 V DC
    • Output Current
  • 25 A
  • 19 A
  • 800 mA
  • 3 A
    • Output Power
    550 W
    Interfaces/Ports
    Plug/Connector
    On/Off Switch
    Receptacles
  • 1 x 20+4pin ATX Motherboard
  • 1 x 4+4pin ATX12V Motherboard
  • 1 x 6+2pin PCI-E
  • 5 x Serial ATA
  • 4 x 4-pin LP4 Peripheral Device
  • 1 x 4-pin SP4 Floppy Drive
  • 1 x 6-pin PCI-E
    • Physical Characteristics
    Form Factor
    Internal
    Height
    3.4"
    Width
    5.9"
    Depth
    5.5"
    Weight (Approximate)
    4.76 lb
    Miscellaneous
    Compatibility
    Intel Core Processors:
    • 2 Duo
    • Quad
    • Extreme
    • i7
    • i5

    AMD Processors:

    • Athlon 64X2
    • Phenom II
    Environmentally Friendly
    Yes
    Energy Efficiency Certification
    80 Plus Bronze
    Energy Efficiency Compliance
    Energy-related Products Directive Lot 6 (ErP Lot 6)
    Environmental Compliance
  • Waste Electrical and Electronic Equipment Directive (WEEE)
  • Restriction of Hazardous Substances (RoHS)
    • Warranty
    Limited Warranty
    3 Year
