SPECIFICATIONS
Specifications
- Mfr Part Number: DAP-1860
- Features:
- MU-MIMO technology handles high-bandwidth network traffic on multiple devices at the same time
- Smart Signal Indicator will help you find the best location optimal Wi-Fi coverage throughout the home
- 11AC Wi-Fi Dual Band Connectivity - Up to 1,732Mbps on the 5GHz band and 800Mbps on the 2.4GHz band for maximum throughput with less Wi-Fi interference
- SmartConnect - Allocates the best possible band for optimal Wi-Fi performance
- Smart BeamForming tracks your connected devices for enhanced Wi-Fi speed
- Built-in setup wizard and QRS Mobile app for simple setup and configuration
- AP mode ideal for homes that are pre-wired for Ethernet or for extended coverage
- Standards: IEEE 802.11 a/g/n/ac, IEEE 802.3ab
- Connectivity: 4x4 MIMO Configuration, 10/100/1000 Gigabit Ethernet Port
- Antenna: 4x adjustable external antennas
- Device Interfaces: Power Switch, Reset Button, WPS Button
- LEDs: Status/WPS, Wi-Fi Signal Strength Indicator
- MIMO Configuration: 4 Transmit/4 Receive
- Operating Frequencies:
- 2.4GHz Band: 2400 - 2483 MHz ISM Band
- 5GHz Band: 5180 - 5850 MHz
- Data Rate:
- 2.4GHz: 800Mbps
- 5GHz: 1732Mbps
- SmartConnect: SmartConnect Technology allocates the best possible band for optimal performance
- Smart BeamForming: Smart BeamForming tracks your connected devices for enhanced Wi-Fi speed and range
- Power: 100-125 V AC, 50/60 Hz, 15 A
- Certifications: UL, FCC, W-Fi
- Dimensions: 6.25 x 3.00 x 2.75 inch
- Weight: 14.3 ounces
- Package Contents:
- AC2600 Wi-Fi Range Extender
- Ethernet cable
- Quick install guide
