Highlights:
  • Output Power: 1200 W
  • Plug/Connector: On/Off Switch
  • Condition: New
  • Category: Power Devices
Contact sales for pricing

Antec's HCP-1200 unifies raw power with advanced PSU engineering to meet the demands of high performing PCs. A full-featured, 80 PLUS Gold certified unit, the HCP-1200 is capable of outputting 99 percent of its rated power on eight +12V rails, ensuring CPU and graphics card compatibility. Exclusive to the High Current series, HCP-1200 boasts High Current heavy-gauge 16 AWG wiring that boosts conductivity, increasing efficiency and improving power delivery. In addition, a cool-running dual double-layer PCB, onboard DC-to-DC converters and Active Power Factor Correction (PFC) provide substantial voltage stability. To experience kilowatt-class power in an unmatched design, pick up Antec's HCP-1200.

General Information
Manufacturer
Antec, Inc
Manufacturer Part Number
HCP-1200
Manufacturer Website Address
http://www.antec.com/us/
Brand Name
Antec
Product Series
HCP
Product Model
HCP-1200
Product Name
HCP-1200 ATX12V & EPS12V Power Supply
Product Type
Power Supply
Technical Information
Specification Compliance
ATX12V/EPS12V
Efficiency
92%
Power Factor Correction (PFC)
Active
Number of Fans
1
Protection Type
  • Over Current
  • Over Voltage
  • Over Power
  • Over Temperature
  • Short Circuit
  • Modular
    Yes
    ATI CrossFire Supported
    Yes
    NVIDIA SLI Supported
    Yes
    Reliability
    MTBF
    100000 Hour
    Power Description
    Number of +12V Rails
    8
    Input Voltage Type
    AC
    Input Voltage
  • 110 V AC
  • 220 V AC
  • Input Voltage Range
    100 V AC to 240 V AC
    Output Voltage
  • 3.3 V DC @ 25 A
  • 5 V DC @ 25 A
  • 12 V DC @ 30 A
  • -12 V DC @ 500 mA
  • 5 V DC @ 4 A
  • Input Current
  • 15 A @ 110V
  • 7 A @ 220V
  • Output Power
    1200 W
    Interfaces/Ports
    Plug/Connector
    On/Off Switch
    Receptacles
  • 1 x 20+4pin ATX Motherboard
  • 1 x 4+4pin ATX12V Motherboard
  • 1 x 8-pin EPS12V Motherboard
  • 8 x 6+2pin PCI-E
  • 12 x 15-pin Serial ATA
  • 9 x 4-pin LP4 Peripheral Device
  • 1 x 4-pin SP4 Floppy Drive
  • Physical Characteristics
    Form Factor
    Internal
    Height
    3.4"
    Width
    5.9"
    Depth
    7.1"
    Weight (Approximate)
    6.50 lb
    Miscellaneous
    Package Contents
    • HCP-1200 ATX12V & EPS12V Power Supply
    • 8-Pin Modular Connector
    • 2 x 8-Pin CPU Connectors
    Environmentally Friendly
    Yes
    Environmental Certification
  • 80 Plus Gold
  • RoHS
  • Country of Origin
    China
    Warranty
    Limited Warranty
    5 Year
