Highlights:
  • Product Type: SAS Controller
  • Host Interface: PCI Express 2.0 x8
  • Platform Supported: PC | Mac
  • RAID Levels: 0 | 1 | 4 | 5 | 6 | 10 | 40 | 50 | 60 | JBOD | DVRAID
Contact sales for pricing
The ExpressSAS R60F RAID adapter provides the most flexible and robust 6Gb/s SAS/SATA connectivity to Direct Attached Storage via 16 internal ports. With transfer rates of up to 1200MB/s per port, the R60F is well suited for high-bandwidth workflows, such as digital content creation, streaming video and audio, transactional databases, and email and Web servers.

The R60F combines advanced engineering and innovative features to ensure smooth data transfers and consistent performance. Leveraging ATTO's market-tested RAID stack and exclusive latency management features, the R60F helps customers create, share and protect data and digital assets more effectively.
General Information
Manufacturer
Atto Technology
Manufacturer Part Number
ESAS-R60F-000
Manufacturer Website Address
http://www.attotech.com
Brand Name
ATTO
Product Line
ExpressSAS
Product Model
ESAS-R60F-000
Product Name
ExpressSAS R60F
Product Type
SAS Controller
Technical Information
Host Interface
PCI Express 2.0 x8
Controller Type
  • Serial ATA/600
  • 6Gb/s SAS
  • RAID Supported
    Yes
    RAID Levels
  • 0
  • 1
  • 4
  • 5
  • 6
  • 10
  • 40
  • 50
  • 60
  • JBOD
  • DVRAID
  • Interfaces/Ports
    Total Number of SAS Ports
    4
    Number of SAS Ports (Internal)
    4
    SAS Connector Details
    4 SFF-8087
    Physical Characteristics
    Height
    2.8"
    Width
    8.6"
    Form Factor
    Plug-in Card
    Card Height
    Low-profile
    Weight (Approximate)
    1.20 lb
    Miscellaneous
    Package Contents
    • ExpressSAS R60F 16-port SAS RAID Controller
    • Full-Height Bracket
    Platform Supported
  • PC
  • Mac
  • Environmentally Friendly
    Yes
    Environmental Certification
    RoHS-6
    Warranty
    Limited Warranty
    3 Year
