Highlights:
  • Sound Channels: 5.1
  • Host Interface: USB
  • Number of Headphone Ports: 4
  • Platform Supported: Mac | PC
Contact sales for pricing

Compact 5.1-channel USB sound card and headphone amplifier with 192kHz/24-bit HD sound and Sonic Studio suite

  • True 5.1-channel HD (192kHz/24-bit) surround sound from a compact USB-powered device
  • 104dB signal-to-analog ratio (SNR) ensures pure sound
  • Sonic Studio provides complete control over loads of sound technologies
  • Perfect Voice technology eliminates noises for clear in-game communications
  • Independent mic and master-volume controls for instant in-game adjustments
  • Integrated headphone amplifier provides clear, detailed sound for an immersive audio experience

A compact audio solution for incredible sound

Xonar U5 is a compact 5.1-channel USB sound card designed to provide PC gamers with high quality audio for games, music and movies. It follows in the footsteps of the award-winning Xonar U7 - providing you with strong and clear sound via headphones, and producing more impactful and detailed audio than onboard hardware. The Xonar U5 has no standalone power supply and connects to your PC via USB, allowing you to instantly plug-in without having to open the PC case.

Take complete control of your audio with Sonic Studio

Xonar U5 features the latest Sonic Studio software suite, so you have full control over every audio setting ranging from equalization (EQ) to 5.1-speaker level-balancing. Sonic Studio has a single navigation page that puts everything in front of you, with an intuitive point-and-click interface that allows you to pre-set audio profiles to suit different audio requirements.

General Information
Manufacturer
ASUS Computer International
Manufacturer Part Number
Xonar U5
Manufacturer Website Address
http://usa.asus.com
Brand Name
Asus
Product Line
Xonar
Product Model
U5
Product Name
Xonar U5 USB Soundcard and Headphone Amplifier
Product Type
External Sound Box
Technical Information
Audio Processor Manufacturer
C-Media
Audio Processor Model
CM6631A
Host Interface
USB
Signal to Noise Ratio (SNR)
104 dB
Minimum Frequency Response
10 Hz
Maximum Frequency Response
44 kHz
Maximum Playback Sampling Rate
3 Byte 192 kHz
Maximum Recording Sampling Rate
3 Byte 192 kHz
Sound Channels
5.1
Platform Supported
  • Mac
  • PC
  • Interfaces/Ports
    USB
    Yes
    Number of Audio Line In
    1
    Number of Headphone Ports
    4
    Number of Audio Line Out
    1
    S/PDIF Out
    Yes
    Number of Digital Audio Coaxial Output
    1
    Physical Characteristics
    Form Factor
    External
    Height
    1"
    Width
    3.1"
    Thickness
    5.1"
    Weight (Approximate)
    1.39 lb
    Miscellaneous
    Package Contents
    • Xonar U5 USB Soundcard and Headphone Amplifier
    • 1 x S/PDIF Adapter
    • 1 x USB Cable
    • 1 x Driver CD
    • 1 x User Manual
    System Requirements
    Operating System(s):
    • Windows 8.1 86x64
    • Windows 8 (32/64 bit)
    • Windows 7 (32/64 bit)
    • Mac Os X
    Environmentally Friendly
    Yes
    Environmental Certification
    RoHS
