The following documentation is intended to explain the procedure for deploying the helm package manager in a Kubernetes environment. This tutorial assumes you have a working knowledge of Kubernetes and a receptive understanding of helm.
Helm is a tool that streamlines installing and managing Kubernetes applications. Think of it like apt/yum/homebrew for Kubernetes. Helm has two parts: a client ( helm ) and a server ( tiller ) Tiller runs inside of your Kubernetes cluster and manages releases (installations) of your charts.
Pre-Requisites:
- Linux Workstation
- K8 Cluster with no other load balancer installed
- Kubernetes-cli or kubectl program
- Kubernetes version v1.15.1 (any version should work)
- Routable IP network with DHCP configured
For a tutorial on Building a K8s Cluster using Vagrant visit: Building a K8s Cluster using Vagrant.
Step 1) Downloading Helm
To install helm, we first need to download the package file. In your browser, navigate to https://helm.sh/docs/using_helm/ . In the page, scroll down to “INSTALLING THE HELM CLIENT” and click where it says “Download your own version”. Find the version you want to download. In this demo, we are downloading "Linux amd64". Right-click the link and copy the "Link Address".
On your master server download the helm package using the link address with wget.
wget https: //get.helm.sh/helm-v2.16.0-linux-amd64.tar.gz |
Next, uncompress the file and change into the linux-amd64 directory and list the files.
[vagrant @kmaster linux-amd64]$ tar -xvf helm-v2. 16.0 -linux-amd64.tar.gz [vagrant @kmaster linux-amd64]$ cd linux-amd64/ [vagrant @kmaster linux-amd64]$ ls helm LICENSE README.md tiller |
Step 2) Install Helm
Installing helm is as easy as copying the binary into your path. Copy the helm binary to /usr/local/bin.
[vagrant @kmaster linux-amd64]$ sudo cp helm /usr/local/bin/ |
Very the install and version. You can do so by running.
vagrant @kmaster :~/linux-amd64$ helm version -- short --client Client: v2. 16.0 +ge13bc94 |
the configuration for helm will be installed under .helm directory under your home directory. However, it will not appear until we initialize helm later down the line "helm init".
Step 3) Installing Tiller
Service accounts are for processes, which run in pods and allow cluster users to create service accounts for specific tasks.
Next, we will install the server-side component (tiller). But we will first need to set up a service account and clusterrolebinding. To create the service account "tiller" type the following:
[vagrant @kmaster linux-amd64]$ kubectl -n kube-system create serviceaccount tiller serviceaccount/tiller created |
Next, we will create the role binding. What we want to do is create a clusterrole called tiller and add the cluster-admin role and associate it with the service account we created earlier tiller under the namespace kube-system.
[vagrant @kmaster linux-amd64]$ kubectl -n kube-system create clusterrolebinding tiller --clusterrole cluster-admin --serviceaccount=kube-system:tiller clusterrolebinding.rbac.authorization.k8s.io/tiller created |
We can check that the clusterrolebinding was created.
[vagrant @kmaster linux-amd64]$ kubectl get clusterrolebinding tiller NAME AGE tiller 65s |
Step 4) Initializing Helm
Now, the next thing to do is initialize helm. When this is done it will create the tiller pod. First, let's look at what pods exist. From the command below you can see that there is no tiller pod running:
[vagrant @kmaster linux-amd64]$ kubectl get pods -n kube-system NAME READY STATUS RESTARTS AGE coredns-5c98db65d4-5497l 1 / 1 Running 0 5h13m coredns-5c98db65d4-s868z 1 / 1 Running 0 5h13m etcd-kmaster.example.com 1 / 1 Running 0 5h12m kube-apiserver-kmaster.example.com 1 / 1 Running 0 5h12m kube-controller-manager-kmaster.example.com 1 / 1 Running 0 5h12m kube-flannel-ds-amd64-fbrpg 1 / 1 Running 0 5h13m kube-flannel-ds-amd64-h47cd 1 / 1 Running 0 5h8m kube-flannel-ds-amd64-p9g2l 1 / 1 Running 0 5h11m kube-proxy-5lwpm 1 / 1 Running 0 5h11m |
Let's initialize helm and we should see that add tiller pod is created.
vagrant @kmaster :~/linux-amd64$ helm init --service-account tiller Creating /home/vagrant/.helm Creating /home/vagrant/.helm/repository Creating /home/vagrant/.helm/repository/cache Creating /home/vagrant/.helm/repository/local Creating /home/vagrant/.helm/plugins Creating /home/vagrant/.helm/starters Creating /home/vagrant/.helm/cache/archive Creating /home/vagrant/.helm/repository/repositories.yaml Adding stable repo with URL: https: //kubernetes-charts.storage.googleapis.com Adding local repo with URL: http: //127.0.0.1:8879/charts $HELM_HOME has been configured at /home/vagrant/.helm. Tiller (the Helm server-side component) has been installed into your Kubernetes Cluster. Please note: by default , Tiller is deployed with an insecure 'allow unauthenticated users' policy. To prevent this , run `helm init` with the --tiller-tls-verify flag. For more information on securing your installation see: https: //docs.helm.sh/using_helm/#securing-your-helm-installation |
After applying the changes we should see a pod was created for tiller.
vagrant @kmaster :~/linux-amd64$ kubectl get pods -n kube-system NAME READY STATUS RESTARTS AGE calico-kube-controllers-7b9dcdcc5-fttk7 1 / 1 Running 1 43h calico-node-6jpjv 1 / 1 Running 1 43h calico-node-bc8db 1 / 1 Running 1 43h calico-node-qrxjw 1 / 1 Running 1 43h coredns-5644d7b6d9-8vflt 1 / 1 Running 1 43h coredns-5644d7b6d9-spp2d 1 / 1 Running 1 43h etcd-kmaster 1 / 1 Running 1 43h kube-apiserver-kmaster 1 / 1 Running 1 43h kube-controller-manager-kmaster 1 / 1 Running 1 43h kube-proxy-bd7fz 1 / 1 Running 1 43h kube-proxy-hdfwx 1 / 1 Running 1 43h kube-proxy-wdsng 1 / 1 Running 1 43h kube-scheduler-kmaster 1 / 1 Running 1 43h tiller-deploy-68cff9d9cb-46r9w 1 / 1 Running 0 32s |
Step 5) Useful Helm Commands
Now that we have the helm binary installed and the server component tiller running in Kubernetes. We can look at some useful commands. Helm help has some very useful commands.
helm help
helm install )—values) (--name_
helm fetch
helm list
helm status
helm search
helm repo update
helm upgrade
helm rollback
helm delete (--purge)
helm reset (--force (--remove-helm-home)
Before running helm commands we should update the repo
[vagrant @kmaster ~]$ helm repo update |
Now we're ready to run some useful helm commands. for starters, helm home will show us the location of the helm director.
[vagrant @kmaster ~]$ helm home /home/vagrant/.helm |
helm repo list will show us the repository that helm uses. This gets added when you initialize helm.
[vagrant @kmaster ~]$ helm repo list NAME URL stable https: //kubernetes-charts.storage.googleapis.com local http: //127.0.0.1:8879/charts |
helm search allows you to search the repo for applications such as nginx.
[vagrant @kmaster ~]$ helm search nginx NAME CHART VERSION APP VERSION DESCRIPTION stable/nginx-ingress 1.24 . 5 0.26 . 1 An nginx Ingress controller that uses ConfigMap to store ... stable/nginx-ldapauth-proxy 0.1 . 3 1.13 . 5 nginx proxy with ldapauth stable/nginx-lego 0.3 . 1 Chart for nginx-ingress-controller and kube-lego stable/gcloud-endpoints 0.1 . 2 1 DEPRECATED Develop, deploy, protect and monitor your APIs... |
If you want to see what's inside nginx you can inspect it with "helm inspect".
helm inspect stable/nginx-ingress |
if you want to install nginx you can fetch the application. What this will do is download a tar file of the application that you can then extract and install.
[vagrant @kmaster ~]$ helm fetch stable/nginx-ingress [vagrant @kmaster ~]$ ls nginx-ingress- 1.24 . 5 .tgz [vagrant @kmaster ~]$ tar -xvf nginx-ingress- 1.24 . 5 .tgz [vagrant @kmaster ~]$ cd nginx-ingress/ [vagrant @kmaster nginx-ingress]$ ls Chart.yaml ci OWNERS README.md templates values.yaml |
If we look in the templates directory, we’ll see all the yaml files that tiller will execute when we install nginx using helm.
[vagrant @kmaster nginx-ingress]$ ls templates/ addheaders-configmap.yaml controller-metrics-service.yaml controller-service.yaml default -backend-service.yaml admission-webhooks controller-poddisruptionbudget.yaml controller-webhook-service.yaml _helpers.tpl clusterrolebinding.yaml controller-prometheusrules.yaml default -backend-deployment.yaml NOTES.txt clusterrole.yaml controller-psp.yaml default -backend-poddisruptionbudget.yaml proxyheaders-configmap.yaml controller-configmap.yaml controller-rolebinding.yaml default -backend-psp.yaml tcp-configmap.yaml controller-daemonset.yaml controller-role.yaml default -backend-rolebinding.yaml udp-configmap.yaml controller-deployment.yaml controller-serviceaccount.yaml default -backend-role.yaml controller-hpa.yaml controller-servicemonitor.yaml default -backend-serviceaccount.yaml |
The below command we can see we've created the deployment, which then created the replicaset, which then created the pod. We also added a service account and clusterrolebinding.
vagrant @kmaster :~/linux-amd64$ kubectl -n kube-system get deploy,replicaset,pod,serviceaccount,clusterrolebinding | grep tiller deployment.apps/tiller-deploy 1 / 1 1 1 8m25s replicaset.apps/tiller-deploy-68cff9d9cb 1 1 1 8m25s pod/tiller-deploy-68cff9d9cb-46r9w 1 / 1 Running 0 8m25s serviceaccount/tiller 1 10m clusterrolebinding.rbac.authorization.k8s.io/tiller 10m |
And there you have had it! Helm in Kubernetes.
Final Thoughts
Why Helm?
Because Kubernetes can become very complex with all its objects, such as Services, ConfigMaps, Persistent Volumes, Pods. Helm in Kubernetes helps to manage these things and offers a simple way to package everything into a simple application. Helm fills the need to quickly and reliably provision container applications through the easy install, update, and removal. It provides a vehicle for developers to package their applications and share them with the Kubernetes community. Whether you are a Developer trying to package your application as a Kubernetes application or a DevOps person trying to deploy either internal or third-party vendor applications. Helm is the way to go!
